Stainless steel ball valve Elephant ksfpt-304-180-ham, body material - – Valve Elephant
Elephant  |  SKU: D160-38141

Stainless steel ball valve Elephant ksfpt-304-180-ham, body material - stainless steel AISI 304, ball material - stainless steel AISI 304, seal - PTFE, handle operated

€120,24
Tax included Shipping calculated at checkout.

Stainless steel ball valve Elephant ksfpt-304-180-ham, body material - stainless steel AISI 304, ball material - stainless steel AISI 304, seal - PTFE, handle operated - DN15 / 40 bar is backordered and will ship as soon as it is back in stock.

Delivery and Shipping

The delivery cost is determined during the checkout process and varies based on several factors, including the product type, delivery time, service provider, and destination country.

If you have any questions about our products, delivery options, or anything else, feel free to reach out.

Description

A stainless steel ball valve is a reliable and versatile device for controlling the flow of liquids and gases in various industrial sectors. Made from corrosion-resistant stainless steel, it possesses high strength and can withstand both high temperatures and pressures. Ball valves are easy to operate, provide secure sealing, and minimize the risk of leaks, making them an ideal choice for use in the oil and gas industry, water treatment plants, the food industry, and other areas where a reliable and durable valve is needed to regulate the flow of substances.





Technical Data Ball Valve Elephant BV3131P(3pc)-FP-F-ISO-H HAM RQN-Z:

Nominal diameter, mm 15-100
Working pressure PN, bar DN15-50 – 40
DN65-80 – 25
DN100 – 16
Temperature of working environment t, ⁰C from -20 to +180
Working environment Water, steam, petroleum products and other liquid or gaseous media that are neutral to the materials of the tap
Connection to the pipeline flanged
Type of flow section full bore
Control type Double-acting pneumatic actuator Elephant-DA





Ball Valve Detail Elephant BV3131P(3pc)-FP-F-ISO-H HAM RQN-Z



Material Specification Ball Valve Elephant BV3131P(3pc)-FP-F-ISO-H HAM RQN-Z:

No. Name Material Quantity
1 Frame SS304/SS316 1
2 Ball valve SS304/SS316 1
3 Bolt SS201/SS304 4-6
4 screw SS201/SS304 6-12
5 Sealing PTFE 1
6 Stock SS304/SS316 1
7 Seal SS201/SS304 1
8 Lid WCB/CF8/CF8M 2
9 Saddle rings PTFE 2
10 Thrust washer PTFE 1





Sketch of ball valve Elephantu BV3131P(3pc)-FP-F-F-ISO-H HAM RQN-Z





Overall and installation dimensions of ball valve Elephant BV3131P(3pc)-FP-F-ISO-H HAM RQN-Z:

DN, mm d, mm D, mm L1, mm L±1.5, mm H, mm
15 15 95 80 130 48
20 20 105 80 150 48
25 25 115 80 160 48
32 32 140 80 180 48
40 38 150 80 200 48
50 50 165 80 230 48
65 64 184 80 290 48
80 79 200 80 310 48
100 99 220 100 350 58





Main technical data and characteristics HAM RQNx-xZ-x gearboxes:

Ambient temperature, ⁰C -30 to +120
Enclosure protection class IP67
Application for various industries where fluid flow control is required
Mounting horizontal/vertical
Stroke adjustment 0 - 90° (adjustable ±5°)
Connection standard ISO 5211

HAM gearboxes





Basic materials of HAM gearbox components:

Name Material
1 Bolt stainless steel 304
2 Index ABS plastic
3 Cover aluminum alloy
4 Sealing ring NBR70
5 Pin black steel
6 Worm gear ductile iron
7 Seal NBR70
8 Housing aluminum alloy
9 Adjusting bolt black steel
10 Gasket stainless steel 304
11 Adjusting nut stainless steel 304
12 Nut cover NBR70
13 Bearing powder steel
14 Worm shaft steel 45
15 Seal NBR70
16 Drive shaft stainless steel 304
17 Handwheel polyester coated carbon steel
18 Pin black steel

HAM sketch RQNx-xZ-x





Overall and mounting dimensions of HAM RQNx-xZ-x gearboxes:

Model HAM
RQN1-180Z-T40
HAM
RQN2-300Z- T37
HAM
RQN3-540Z- T36
HAM
RQN4-675Z- T36
HAM
RQN5-1500Z- T50
D, mm 80 100 120 142 175
D1, mm 70 90 102 125 140
D2, mm 50 70 70 102 102
n-M1 4-M6x10 4-M8x12 4-M8x10 4-M8x10 4-M8x10
n-M2 4-M8x12 4-M10x12 4-M10x15 4-M12x18 4-M16x24
S, mm 17x17 17x17 22x22 24x24 27x27
L, mm 115 130 150 180 220
L1, mm 50 58 65 80 95
L2, mm 42 50 60 60 78
H, mm 48 58 58 74 84
H1, mm 19 18 18 21 51
d1, mm 20 20 20 20 25
L3, mm 160 160 215 225 325
W, mm 140 200 250 300 400

HAM sketch RQNx-xZ-x





Technical data of HAM RQNx-xZ-x gearboxes:

Model HAM
RQN1-180Z-T40
HAM
RQN2-300Z- T37
HAM
RQN3-540Z- T36
HAM
RQN4-675Z- T36
HAM
RQN5-1500Z- T50
Gear ratio 40:1 37:1 36:1 36:1 50:1
Torque, Nm 180 300 540 675 1500
ISO flange type F05/F07 F07/F09 F07/F10 F10/F12 F10/F14
Weight, kg 1.2 2

Specifications

  • Country of origin
    China
  • Port opening
    Full Port
  • Configuration
    Two-way
  • Body material
    Stainless steel AISI 304/1.4301
  • Material ball
    Stainless steel AISI 304/1.4301
  • Material ball seal
    PTFE
  • Maximum allowable temperature
    180 °C
  • Connection type
    Flanged
  • Control type
    Gear
  • Operating environment
    Water, Air, Oil Products
  • Applications
    Water Supply, Heat Supply
  • Valve feedback
    No
  • Explosion-proof
    No
  • Torque
    300 Nm
  • Manual override
    Yes

Reviews (0)

Documentation

Payment & Security

Payment methods

    Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

    Available Variants

    SKUConnection sizePressurePrice AvailabilityQuantity Add to cart
    D160-38141DN1540 bar €120,24 0 in stock
    D160-38140DN2040 bar €133,97 Out of stock
    D160-38139DN2540 bar €104,48 Out of stock
    D160-38138DN3240 bar €133,73 Out of stock
    D160-38137DN4040 bar €149,49 Out of stock
    D160-38136DN5040 bar €177,88 Out of stock
    D160-38135DN6525 bar €236,28 Out of stock
    D160-38134DN8025 bar €279,17 Out of stock
    D160-38133DN10016 bar €495,97 Out of stock
