Water Butterfly valves Elephant BV3232P-FP-Fb-ISO-H DN80-100 16 bar fu – Valve Elephant
Elephant  |  SKU: D160-37132

Water Butterfly valves Elephant BV3232P-FP-Fb-ISO-H DN80-100 16 bar full bore wafer type, body - stainless steel AISI 316, seal - PTFE, with pneumatic actuator Elephant PA-DA-105-1 and APL-410N EX

€1.184,58
Tax included Shipping calculated at checkout.

Delivery and Shipping

The delivery cost is determined during the checkout process and varies based on several factors, including the product type, delivery time, service provider, and destination country.

If you have any questions about our products, delivery options, or anything else, feel free to reach out.

Description

The ball valve is used as a shut-off valve in heat supply systems, water supply systems, in steam, fuel and pneumatic systems with compressed air and neutral gases. Installation of valves of this series is possible in systems transporting liquid and gaseous media (water, oil, oils, steam, air, alcohols, glycol, etc.), non-aggressive to the materials of the valve. The use of ball valves as control valves is not allowed.
The rotary pneumatic actuator is designed to automate the process of controlling industrial valves.
The limit switch unit is an electrical device designed to open and close the working circuit and to visualize the positions of the shut-off element of the pipeline valves. In the terminal box, as a rule, there are two mechanical switches rated for voltage up to 250 V, which monitor the position of the actuator rod and signal in extreme positions. They are mounted on top of the actuator surface.

Specifications
  • Operating environment
    Water, Air, Steam, Industrial water, Oil, Oil products
  • Applications
    Heat Supply

Reviews (0)

Documentation

Payment & Security

Payment methods

    Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

    Available Variants

    SKUSizePressurePrice AvailabilityQuantity Add to cart
    D160-37132DN8016 bar €1.184,58 Sold out
    D160-37109DN10016 bar €1.350,12 Sold out
