Elephant  |  SKU: D050-24487

Water Butterfly Valve Elephant WBV1331E-2W-F-H, body material - cast iron GGG40, disk material - stainless steel AISI 304, seal - EPDM, handle

€79,00
Shipping calculated at checkout.

Delivery and Shipping

The delivery cost is determined during the checkout process and varies based on several factors, including the product type, delivery time, service provider, and destination country.

If you have any questions about our products, delivery options, or anything else, feel free to reach out.

Description

The WBV1331E-2W-F-H butterfly valve is designed for use as shut-off or regulating valves for flow control in heat supply systems, water supply systems, in technological processes of food, chemical, oil and gas, pulp and paper and other industries. The valves are opened and closed by turning the disk by 90°. Opening is performed by turning the handle counterclockwise, closing - clockwise.

General mass-dimensional parameters of water butterfly valve Elephant WBV1331E-2W-F-H, body material - cast iron GGG40, disk material - stainless steel AISI 304, seal - EPDM, handle:

Model L, mm L1, mm D, mm D1, mm D2, mm n-d, pcs-mm Weight, kg
DN50 108 230 165 125 99 4-18 4,8
DN65 112 230 185 145 118 4-18 6,75
DN80 114 230 200 160 132 8-18 7,6
DN100 127 230 220 180 156 8-18 8.15
DN125 140 280 250 210 184 8-18 11.6
DN150 140 280 285 240 211 8-22 13.95
DN200 152 380 340 295 266 12-22 21.4



General details and materials of water butterfly valve Elephant WBV1331E-2W-F-H, body material - cast iron GGG40, disk material - stainless steel AISI 304, seal - EPDM, handle:

№ Part name Material
1 Body GGG40 cast iron
2 Disk Stainless steel 304
3 Seat seal EPDM
4 Stem SSS 420 stainless steel
5 Handle GGG40 cast iron


Specifications
  • Country of origin
    China
  • Body material
    cast iron GGG40
  • Maximum allowable temperature
    130 °C
  • Connection type
    flanged
  • Control type
    handle
  • Nominal pressure
    16 bar
  • Type of seal
    EPDM
  • Disc material
    stainless steel AISI 304

Reviews (0)

Payment & Security

Payment methods

    Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

    Available Variants

    SKUConnection sizePressurePrice AvailabilityMax TemperatureQuantity Add to cart
    D050-24487DN5016 bar €79,00 5 in stock 130 °C
    D050-24488DN6516 bar €94,00 5 in stock 130 °C
    D050-24489DN8016 bar €105,00 5 in stock 130 °C
    D050-24490DN10016 bar €130,00 5 in stock 130 °C
    D050-24491DN12516 bar €164,00 5 in stock 130 °C
    D050-24492DN15016 bar €199,00 5 in stock 130 °C
    D050-24493DN20016 bar €315,00 5 in stock 130 °C
