Two way normally open indirect acting electric solenoid valve Elephant – Valve Elephant
Elephant  |  SKU: D130-02427

Two way normally open indirect acting electric solenoid valve Elephant DHDF21-NO 24V, body material - brass, seal - Viton

€292,55
Tax included Shipping calculated at checkout.

Two way normally open indirect acting electric solenoid valve Elephant DHDF21-NO 24V, body material - brass, seal - Viton - DN10 / 16 bar is backordered and will ship as soon as it is back in stock.

Delivery and Shipping

The delivery cost is determined during the checkout process and varies based on several factors, including the product type, delivery time, service provider, and destination country.

If you have any questions about our products, delivery options, or anything else, feel free to reach out.

Description

The DHDF21 electromagnetic fountain solenoid valve is designed specifically for controlling water jets in dynamic fountains. Its IP 68 protection rating allows for installation directly inside the water feature, eliminating the need to move it to a dry location. The electromagnetic solenoid valve is a functional and reliable pipeline valve. Its special electromagnetic coils have a service life of up to 1 million activations. The average response time for a membrane solenoid valve ranges from 30 to 500 milliseconds, depending on the diameter, pressure, and design. Electromagnetic valves can be used as remote control shutoff devices or for safety, such as shutoff, switching, or isolating solenoid valves. A normally open valve operates by maintaining the valve open while static and closing it when voltage is applied to the coil. To maintain the normally open valve in the closed position, voltage must be applied to the coil continuously.





Overall and installation dimensions of electromagnetic valves Elephant DHDF21-NO 24V

DN Passage diameter Hole diameter A B H Weight
10 3/8" 13 66 48 124 1.42
15 1/2" 13 66 48 124 1.42
20 3/4" 20 75 58 130 1.52
25 1" 25 96 70 143 1.8
32 1 1/4" 32 131 96 158 3.15
40 1 1/2" 40 131 96 158 3.05
50 2" 50 165 120 179 4.8

Клапаны электромагнитные соленоидные двухходовые DN.ru-DHDF21-NO-S погружные фонтанные пилотного действия Ду10-50 (3/8-2 дюйм) Ру16, корпус - сталь 304, с катушкой 24В

Sketch of the electromagnetic valve Elephant DHDF21-NO 24V

Specifications

  • Body material
    Brass
  • Maximum allowable temperature
    80 °C
  • Connection type
    Threaded NPT/BSP
  • Operating environment
    Water, Air, Liquid Medium
  • Applications
    Heating Systems, Irrigation Systems, Ventilation Systems
  • Nominal pressure
    16 bar
  • Type of seal
    VITON
  • Solenoid valve type
    Normally open
  • Solenoid valve working principles
    Indirect acting
  • Voltage
    24V DC

Reviews (0)

Documentation

Payment & Security

Payment methods

    Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

    Available Variants

    SKUConnection sizePressurePrice AvailabilityQuantity Add to cart
    D130-02427DN1016 bar €292,55 0 In stock
    D130-02428DN1516 bar €292,55 0 In stock
    D130-02429DN2016 bar €322,38 0 In stock
    D130-02430DN2516 bar €395,99 0 In stock
    D130-02431DN3216 bar €656,67 0 In stock
    D130-02432DN4016 bar €656,67 0 In stock
    D130-02433DN5016 bar €925,34 0 In stock
