Elephant  |  SKU: D130-02772

Two way normally open indirect acting electric solenoid valve Elephant DHA11-NO 24V, body material - stainless steel AISI 304, seal - NBR

€110,51
Tax included Shipping calculated at checkout.

Two way normally open indirect acting electric solenoid valve Elephant DHA11-NO 24V, body material - stainless steel AISI 304, seal - NBR - DN20 / 6 bar is backordered and will ship as soon as it is back in stock.

Delivery and Shipping

The delivery cost is determined during the checkout process and varies based on several factors, including the product type, delivery time, service provider, and destination country.

If you have any questions about our products, delivery options, or anything else, feel free to reach out.

Description

The DHA11 solenoid valve is widely used for automatic irrigation in agriculture, garden landscaping, drip irrigation, and other automated control systems. The solenoid valve is a functional and reliable pipeline valve. Its special solenoid coils have a service life of up to 1 million activations. The actuation time of the membrane solenoid valve averages 30 to 500 milliseconds, depending on the diameter, pressure, and design. Solenoid valves can be used as remote control shutoff devices or for safety, as shutoff, switching, or isolating solenoid valves. A normally-open valve operates by maintaining the valve open while static and closing it when voltage is applied to the coil. To maintain the normally-open valve in the closed position, voltage must be applied to the coil continuously.





Overall and installation dimensions of electromagnetic valves Elephant DHA11-NO 24V

DN Passage diameter Passage diameter A B C
15 1/2" 15 85 73 126
20 3/4" 20 90 73 128
25 1" 25 125 90 148
32 1 1/4" 32 150 128 173
40 1 1/2" 40 151 128 176
50 2" 50 170 140 190

Клапаны электромагнитные соленоидные двухходовые DN.ru-DHA11-NO нормально-открытые, пилотного действия, для оросительных систем Ду20-100 (3/4 - 4 дюйм) Ру16, корпус - сталь 304, с катушкой 24В

Sketch of the electromagnetic valve Elephant DHA11-NO 24V

Specifications

  • Body material
    Stainless steel AISI 304/1.4301
  • Maximum allowable temperature
    80 °C
  • Connection type
    Threaded NPT/BSP
  • Operating environment
    Water, Air, Liquid Medium
  • Applications
    Heating Systems, Irrigation Systems, Ventilation Systems
  • Nominal pressure
    6 bar
  • Type of seal
    NBR
  • Locking material
    NBR
  • Solenoid valve type
    Normally open
  • Solenoid valve working principles
    Indirect acting
  • Voltage
    24V DC

Reviews (0)

Documentation

Payment & Security

Payment methods

    Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

    Available Variants

    SKUConnection sizePressurePrice AvailabilityQuantity Add to cart
    D130-02772DN206 bar €110,51 0 In stock
    D130-02773DN256 bar €110,51 0 In stock
    D130-02774DN406 bar €375,12 0 In stock
    D130-02775DN506 bar €452,72 0 In stock
    D130-02776DN806 bar €814,89 0 In stock
    D130-02777DN1006 bar €1.422,81 0 In stock
