Multi-turn electric drives Elephant MT-N-xM-O2-220VAC-U1 220V five-cam
Multi-turn electric drives Elephant MT-N-xM-O2-220VAC-U1 220V five-cam - 005EM 50 Nm is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
The delivery cost is determined during the checkout process and varies based on several factors, including the product type, delivery time, service provider, and destination country.
Description
Description
The multi-turn electric actuator is designed to automate the control of industrial valves and determine the valve shutoff valve position.
The electric actuator operates by converting an electrical signal from the control device into rotary motion of the output shaft.
Technical parameters of multi-turn electric drives Elephant MT-N-xM-O2-220VAC-U1 380V five-cam
| Name | Value |
| Electric Drive Brand | Elephant |
| Electric Drive Type | Multi-turn |
| Power Voltage | 220V |
| Ambient Temperature, °C | -30 to 70 |
| Enclosure Protection Rating, IP | 67 |
| Manual Override | Steering wheel |
| Explosion Protection | no |
Dimensions and sizes of multi-turn electric drives Elephant MT-N-xM-O2-220VAC-U1 220V five-cam
| Model | 005M | 010M | 015M | 020M | 030M | 045M | 060M | 090M |
| W, mm | 334 | 334 | 334 | 365 | 365 | 433 | 433 | 587 |
| H, mm | 258 | 258 | 258 | 290 | 290 | 337 | 337 | 352 |
| L, mm | 411 | 411 | 411 | 470 | 470 | 564 | 564 | 637 |
| DxD, mm | 100х100 | 100х100 | 100х100 | 122х122 | 122х122 | 200х200 | 200х200 | 200х200 |
| D1, mm | 104 | 104 | 104 | 135 | 135 | 220 | 220 | 220 |
| D2, mm | 70 | 70 | 70 | 108 | 108 | 155 | 155 | 155 |
| d1, mm | 32 | 32 | 32 | 45 | 45 | 70 | 70 | 70 |
| d2, mm | 44 | 44 | 44 | 57 | 57 | 84 | 84 | 84 |
| f, mm | 8 | 8 | 8 | 15 | 15 | 22 | 22 | 22 |
| h, mm | 5 | 5 | 5 | 8 | 8 | 11 | 11 | 11 |
| h1, mm | 3 | 3 | 3 | 7 | 7 | 11 | 11 | 11 |
| h2, mm | 18 | 18 | 18 | 22 | 22 | 28 | 28 | 28 |
| 4–M | 4–M12 | 4–M12 | 4–M12 | 4–M12 | 4–M12 | 4–M20 | 4–M20 | 4–M20 |
Schematic diagram of the multi-turn electric drives Elephant MT-N-xM-O2-220VAC-U1 220V five-cam
| № | Name |
| 1 | Electric Motor |
| 2 | Gear Motor |
| 3 | Worm Gear |
| 4 | Worm |
| 5 | Handle |
| 6 | Torque Mechanism |
| 7 | Set of Disc Springs |
| 8 | Opening Indicator |
| 9 | Movement Mechanism |
| 10 | Output Shaft |
| 11 | Worm Gear |
| 12 | Bevel Gear |
