Connectors CLAMP Elephant UC-31-W-x, body - stainless steel 304, welded connection
Connectors CLAMP Elephant UC-31-W-x, body - stainless steel 304, welded connection - DN15 / 10 bar is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
The delivery cost is determined during the checkout process and varies based on several factors, including the product type, delivery time, service provider, and destination country.
Description
Description
CLAMP connectors Elephant UC-31-W-x stainless steel body, weldable are CLAMP quick coupling elements with a rolled part for clamping clamp on one side and an end part for welding on the other side. The CLAMP connection is used in pipeline sections where quick assembly/disassembly of elements is required. This connection is designed for many cycles of connection and disconnection.
Overall and installation dimensions of CLAMP Elephant UC-31-W-34 weld-on fittings, stainless steel 304
| Model | mm | ||||
| ØA | ØC | ØD | E | F | |
| DN15 | 34 | 15 | 18 | 2.85 | 18 |
| DN20 | 34 | 19 | 22 | 2.85 | 18 |
| DN25 | 50.5 | 25 | 28 | 2.85 | 21.5 |
| DN32 | 50.5 | 31 | 34 | 2.85 | 21.5 |
| DN40 | 50.5 | 37 | 40 | 2.85 | 21.5 |
| DN50 | 64 | 49 | 52 | 2.85 | 21.5 |
| DN65 | 91 | 66 | 70 | 2.85 | 28 |
| DN80 | 106 | 81 | 85 | 2.85 | 28 |
| DN100 | 119 | 100 | 104 | 2.85 | 28 |
Dimensional sketch of CLAMP Elephant UC-31-W-34 weld-on sockets, stainless steel 304
Reviews (0)
Reviews (0)
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Available Variants
| SKU | Connection size | Pressure | Price | Availability | Max Temperature | Quantity | Add to cart |
|---|---|---|---|---|---|---|---|
| D270-16843 | DN15 | 10 bar | €3,00 | Out of stock | - | ||
| D270-16844 | DN20 | 10 bar | €3,00 | Out of stock | - | ||
| D270-16845 | DN25 | 10 bar | €3,00 | Out of stock | - | ||
| D270-16846 | DN32 | 10 bar | €3,00 | Out of stock | - | ||
| D270-16847 | DN40 | 10 bar | €2,00 | Out of stock | - | ||
| D270-16848 | DN50 | 10 bar | €3,00 | Out of stock | - | ||
| D270-16849 | DN65 | 10 bar | €6,00 | Out of stock | - | ||
| D270-16850 | DN80 | 10 bar | €7,00 | Out of stock | - | ||
| D270-16851 | DN100 | 10 bar | €8,00 | Out of stock | - |
