Ball valves Elephant BV3131PPL(4pc)-FP-3WT-F-ISO-H DN25 16 bar, three-way, full bore, steel 304, seal - PPL, flanged with 3/4-turn electric actuator E34-N-005EM-O1-220VAC-U1 220V
Ball valves Elephant BV3131PPL(4pc)-FP-3WT-F-ISO-H DN25 16 bar, three-way, full bore, steel 304, seal - PPL, flanged with 3/4-turn electric actuator E34-N-005EM-O1-220VAC-U1 220V - DN25 / 16 bar is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
The delivery cost is determined during the checkout process and varies based on several factors, including the product type, delivery time, service provider, and destination country.
Description
Description
Technical parameters of ball valves Elephant BV3131PPL(4pc)-FP-3WT-F-ISO-H DN25 16 bar
| Name | Value |
| Nominal pressure, bar | 16 |
| Working fluid temperature, °C | from -29 to 200 |
| Valve device type | three-way |
| Three-way valve type | T |
| Application | water supply, heat supply, pneumatic systems |
| Working fluid | water, steam, petroleum products, liquids, neutral media, gaseous media |
| Pipeline connection | flanged |
| Water-dispensing | no |
| Flow area type | full bore |
| Tightness class | A |
| Control type | with electric drive |
| Connection | flanged |
| Control | electric drive 220V |
| Presence of limit switches | yes |
| Average service life, years | 10 |
| Warranty, years | 12 |
| Country of manufacture | China |
Dimensions and sizes of ball valves Elephant BV3131PPL(4pc)-FP-3WT-F-ISO-H DN25 16 bar
| DN | L, mm | D, mm | F, mm | L1, mm |
| 25 | 180 | 115 | 122 | 161 |
Sketch of ball valves Elephant BV3131PPL(4pc)-FP-3WT-F-ISO-H DN25 16 bar
Table of parts and materials for ball valves Elephant BV3131PPL(4pc)-FP-3WT-F-ISO-H DN25 16 bar
| № | Part Name | Material |
| 1 | Rear Cover | AISI 304 stainless steel |
| 2 | Nut | ASTM A194 Gr.8M steel |
| 3 | Bolt | ASTM A193 Gr.B8M Cl2 steel |
| 4 | Ball Seal | PPL |
| 5 | Ball | AISI 304 stainless steel |
| 6 | Cover | AISI 304 stainless steel |
| 7 | Housing | AISI 304 stainless steel |
| 8 | Support Ring | AISI 304 stainless steel |
| 9 | O-Ring Seal | VITON |
| 10 | Threaded Sleeve | AISI 304 stainless steel |
| 11 | Gasket | PPL |
| 12 | Stem | AISI 304 stainless steel |
| 13 | Stem Seal | PPL |
| 14 | Seal | AISI 304 stainless steel |
| 15 | Handle | WCB steel + plastic |
Technical parameters of the electric drive E34-N-005EM-O1-220VAC-U1 220V
| Name | Meaning |
| Model | E34-N-005EM-O1-220VAC-U1 220V |
| Pressure, bar | 2 ÷ 8 |
| Availability of a manual backup | Yes |
